Tapered Smooth (TS) Series
WHATLEY TAPERED SMOOTH LIGHT POLE OVERVIEW
Whatley composite Tapered Smooth (TS) light poles are constructed of continuous fiberglass filament combined with a thermosetting resin using an advanced resin transfer process that yields light poles and lamp posts with exceptional strength and durability.
Whatley offers 3 models of round-tapered smooth composite light poles (TS-Series). These decorative lighting poles are well-suited for streetscape designs and any other installations in which a modern, attractive design aesthetic is desired.
The Whatley TS-Series features a .14-inch per foot taper. Direct-embed and anchor-base models are available in mounting heights from 10' to 35'. The engineered-composite pole is a durable, dent-resistant structure that will not rust, rot, or decay even when subjected to frequent moisture, salt, de-icing solutions, fertilizers, and other harsh conditions.
TS model light poles are available with decorative Whatley Xtreme elastomeric-urethane base covers that provide enduring beauty and long-lasting performance.
Trusted and time proven, the structural integrity of Whatley products makes them an ideal choice for use in high-traffic environments, such as busy streets, boulevards, highways, parks, campuses, and on hike and bike trails.
Use the table below to locate your specified pole height and required EPA values to determine the light pole model number best suited for your needs. Then simply visit the Whatley Decorative Product Selector page to choose a base cover and download a product specification sheet.
Select A Pole
| EPA values calculated as per ANSI C136.20-2012 | ||||||||
| MOUNTING HEIGHT | 90 MPH | 100 MPH | 110 MPH | 120 MPH | 130 MPH | 140 MPH | 150 MPH | SERIES |
| 10 | 11.8 | 9.2 | 7.5 | 6.2 | 5.2 | 4.4 | 3.8 | TS34 |
| 10 | 14.8 | 11.9 | 9.7 | 8.1 | 6.8 | 5.8 | 5.0 | TS45 |
| 11 | 11.3 | 8.8 | 7.2 | 5.9 | 5.0 | 4.2 | 3.6 | TS34 |
| 11 | 15.0 | 12.0 | 9.8 | 8.1 | 6.8 | 5.8 | 5.0 | TS45 |
| 12 | 10.2 | 8.0 | 6.5 | 5.3 | 4.4 | 3.7 | 3.2 | TS34 |
| 12 | 14.1 | 11.2 | 9.1 | 7.6 | 6.4 | 5.4 | 4.7 | TS45 |
| 13 | 9.4 | 7.4 | 5.9 | 4.9 | 4.1 | 3.4 | 2.9 | TS34 |
| 13 | 13.1 | 10.0 | 8.5 | 7.0 | 5.9 | 5.0 | 4.3 | TS45 |
| 14 | 8.7 | 6.8 | 5.5 | 4.5 | 3.7 | 3.1 | 2.6 | TS34 |
| 14 | 12.7 | 10.1 | 8.2 | 6.7 | 5.6 | 4.8 | 4.1 | TS45 |
| 15 | 9.2 | 8.0 | 6.5 | 5.3 | 4.4 | 3.7 | 3.1 | TS34 |
| 15 | 12.5 | 9.9 | 8.0 | 6.6 | 5.5 | 4.7 | 4.0 | TS45 |
| 16 | 9.3 | 7.3 | 5.9 | 4.8 | 4.0 | 3.3 | 2.8 | TS34 |
| 16 | 12.6 | 10.0 | 8.1 | 6.7 | 5.6 | 4.7 | 4.0 | TS45 |
| 17 | 8.6 | 6.7 | 5.4 | 4.4 | 3.6 | 3.0 | 2.5 | TS34 |
| 17 | 11.3 | 8.9 | 7.2 | 5.9 | 4.9 | 4.1 | 3.5 | TS45 |
| 18 | 7.9 | 6.1 | 4.9 | 3.9 | 3.2 | 2.7 | 2.2 | TS34 |
| 18 | 12.2 | 9.6 | 7.8 | 6.4 | 5.3 | 4.5 | 3.8 | TS45 |
| 19 | 7.2 | 5.6 | 4.4 | 3.6 | 2.9 | 2.4 | 2.0 | TS34 |
| 19 | 11.0 | 8.7 | 7.0 | 5.7 | 4.7 | 4.0 | 3.4 | TS45 |
| 20 | 6.6 | 5.1 | 4.0 | 3.2 | 2.6 | 2.1 | 1.8 | TS34 |
| 20 | 10.8 | 8.5 | 6.8 | 5.6 | 4.6 | 3.9 | 3.3 | TS45 |
| 20 | 16.9 | 13.5 | 10.9 | 9.0 | 7.6 | 6.4 | 5.5 | TS50 |
| 21 | 8.2 | 6.4 | 5.1 | 4.1 | 3.4 | 2.8 | 2.3 | TS34 |
| 21 | 10.9 | 8.6 | 6.9 | 5.6 | 4.7 | 3.9 | 3.3 | TS45 |
| 21 | 20.1 | 16.0 | 13.0 | 10.8 | 9.0 | 7.7 | 6.5 | TS50 |
| 22 | 7.5 | 5.8 | 4.6 | 3.7 | 3.0 | 2.5 | 2.1 | TS34 |
| 22 | 8.8 | 6.9 | 5.5 | 4.4 | 3.6 | 3.0 | 2.4 | TS45 |
| 22 | 18.9 | 15.1 | 12.3 | 10.1 | 8.5 | 7.2 | 6.1 | TS50 |
| 23 | 6.9 | 5.3 | 4.2 | 3.3 | 2.7 | 2.2 | 1.8 | TS34 |
| 23 | 8.3 | 5.9 | 5.1 | 4.1 | 3.4 | 2.8 | 2.2 | TS45 |
| 23 | 17.9 | 14.2 | 11.5 | 9.5 | 8.0 | 6.7 | 5.6 | TS50 |
| 24 | 6.3 | 4.9 | 3.8 | 3.0 | 2.4 | 2.0 | 1.6 | TS34 |
| 24 | 8.1 | 6.3 | 5.0 | 4.0 | 3.3 | 2.7 | 2.1 | TS45 |
| 24 | 16.9 | 13.4 | 10.9 | 9.0 | 7.5 | 6.3 | 5.2 | TS50 |
| 25 | 5.8 | 4.4 | 3.4 | 2.7 | 2.1 | 1.7 | 1.3 | TS34 |
| 25 | 7.9 | 6.1 | 4.8 | 3.9 | 3.2 | 2.6 | 2.0 | TS45 |
| 25 | 19.3 | 15.3 | 12.4 | 10.1 | 8.2 | 6.6 | 5.4 | TS50 |
| 26 | 5.3 | 4.0 | 3.1 | 2.4 | 1.9 | 1.5 | 1.1 | TS34 |
| 26 | 7.7 | 6.0 | 4.7 | 3.8 | 3.1 | 2.5 | 1.9 | TS45 |
| 26 | 18.5 | 14.7 | 11.9 | 9.6 | 7.7 | 6.2 | 5.0 | TS50 |
| 27 | 4.9 | 3.6 | 2.8 | 2.1 | 1.7 | 1.3 | 0.9 | TS34 |
| 27 | 6.6 | 5.1 | 4.0 | 3.1 | 2.5 | 2.0 | 1.4 | TS45 |
| 27 | 17.8 | 14.1 | 11.5 | 9.2 | 7.3 | 5.9 | 4.7 | TS50 |
| 28 | 4.4 | 3.3 | 2.5 | 1.9 | 1.4 | 1.1 | 0.7 | TS34 |
| 28 | 6.4 | 4.9 | 3.8 | 3.0 | 2.4 | 1.9 | 1.3 | TS45 |
| 28 | 17.2 | 13.6 | 11.0 | 8.8 | 6.9 | 5.5 | 4.4 | TS50 |
| 29 | 3.9 | 2.9 | 2.1 | 1.6 | 1.2 | 0.9 | 0.5 | TS34 |
| 29 | 14.8 | 11.9 | 9.7 | 8.1 | 6.8 | 5.8 | 5.0 | TS45 |
| 29 | 16.6 | 13.1 | 10.6 | 8.3 | 6.6 | 5.2 | 4.1 | TS50 |
| 30 | 3.5 | 2.5 | 1.8 | 1.3 | 1.0 | 0.7 | 0.3 | TS34 |
| 30 | 5.1 | 3.8 | 2.9 | 2.2 | 1.7 | 1.3 | 0.8 | TS45 |
| 30 | 16.0 | 12.6 | 10.2 | 8.0 | 6.2 | 4.9 | 3.8 | TS50 |
Standard Color Codes
| blk | Black | |
| dbz | Dark Bronze | |
| gry | Grey |
Standard Color Codes
| slv | Silver | |
| wht | White | |
| dgr | Dark Green | |
| htg | Hunter Green | |
| cc | Custom Color min. 3" x 3" color chip |
|
| ral | RAL color 4-digit RAL color code |
|
